TOA Wireless Conference System Delegate Unit TS-802 with TS 903 and BP 900

Wireless Conference System, TOA CTS-802 Delegate Unit with TS 903 and BP 900

The TS-802 is a Delegate unit of the Infrared Conference system. Since the system is cordless, it can be easily installed and removed. It can be operated on either the AD-0910 AC adapter (optional) or the BP-900 lithium-ion battery (optional). It is equipped with a remaining battery indicator. Two types of dedicated microphones are made available for the TS-802 as optional products: the CTS-903 standard type and the TS-904 long type.

Specifications:

Power Source: 7.4 V DC (battery), 9 V DC (AC adapter)
(supplied from BP-900 battery (option) or AD-0910 AC adapter (option))
Current Consumption: Max. 270 mA
Input: Microphone terminal: Combined type of XLR-4-31
(dedicated for connecting the optional TS-903 or TS-904)
Output: Monitor speaker: 8 Ω, 0.2 W
Headphone: Mini jack ? 2
LED Indicator: Speech indicator (flashes when the unit is out of communications range),
Power indicator (flashes when the unit is out of communications range or when the battery level is low)
Battery Life: Approx. 10 hours (when the fully-charged BP-900 battery is used with During speech" to "Standby" ratio of 1:2)"
Operating Temperature: 0? to +40?
Finish: Top panel: ABS resin, gray metallic, paint, semi-matte
Dimensions: 210 (W) ? 65.9 (H) ? 152 (D) mm
Weight: 630 g
Option: Microphone: TS-903, TS-904 (Select either one.)
Lithium-ion battery: BP-900
AC adapter: AD-0910

Infrared Emitter/Detector

Wavelength : 870 nm (AM: Brightness modulation)
Modulation Method : Frequency modulation
Carrier Frequency Transmission: Audio channel 1: 7.35 MHz
                 Audio channel 2: 8.10 MHz
                 Audio channel 3: 8.55 MHz
                 Audio channel 4: 9.15 MHz
                 Control channel: 6.45 MHz
                 Reception: Audio channel: 1.95 MHz
Acceptance Angle Vertical: 90?, Horizontal: 120?
Emission Angle Vertical: 90?, Horizontal: 120?
Covering Range 7 m (radius)
